Power increase

Aeolian Wind Focus Effect

  • Uses existing surface area of a pitched roof to collect and focus the prevailing wind
  • Wind forced to travel over the roof surface
  • Forms a pinch point at the roof ridge
  • Air flow is accelerated through the turbine
  • Measured wind speed around the ridge can be just over three times the actual wind speed
  • Up to nine times the energy is available to it compared to a VAWT (Vertical Axis Wind Turbine) system
Uses existing surface area of a pitched roof to collect and focus the prevailing wind. Wind forced to travel over the roof surface. Forms a pinch point at the roof ridge. Air flow is accelerated through the turbine. Measured wind speed around the ridge can be just over three times the actual wind speed. Up to nine times the energy is available to it compared to a VAWT (Vertical Axis Wind Turbine) system.

Angle 0° 8° 15° 30° 45° 60°
Windspeed x1.0 x1.1 x1.2 x1.5 x2.2 x1.3

Unique Design,Unique Performance Consistent power generation even in turbulent wind conditions Uses advanced aerodynamics to prevent noise in operation Designed to self-limit the speed of the rotor Units achieve full capacity at wind speeds of only 25mph Self-regulating so rotor speed is not exceeded, even in severe storm conditions Low-profile, self-regulating and “planning-friendly” design Ideal for commercial and urban areas with turbulent winds

Unique Design,Unique Performance

  • Consistent power generation even in turbulent wind conditions
  • Uses advanced aerodynamics to prevent noise in operation
  • Designed to self-limit the speed of the rotor
  • Units achieve full capacity at wind speeds of only 25mph
  • Self-regulating so rotor speed is not exceeded, even in severe storm conditions
  • Low-profile, self-regulating and “planning-friendly” design
  • Ideal for commercial and urban areas with turbulent winds

power Designation Wind average speed over 10 minutes (km/h) Wind average speed over 10 minutes (m/sec) Effect on land and in humans
0 stil 0-1 0-0,2 smoke rises straight or almost straight up
1 zwak 1-5 0,3-1,5 wind direction can be clearly deduced from smoke plumes
2 zwak 6-11 1,6-3,3 wind noticeable in face
3 matig 12-19 3,4-5,4 dust blows up
4 matig 20-28 5,5-7,9 hair disheveled, clothes flapping
5 vrij krachtig 29-38 8,0-10,7 blowing dust that bothers the eyes, crested waves on lakes and canals and garbage containers blow over
6 krachtig 39-49 10,8-13,8 holding umbrellas with difficulty
7 hard 50-61 13,9-17,1 difficult to walk or cycle against the wind
8 stormachtig 62-74 17,2-20,7 moving very difficult
9 storm 75-88 20,8-24,4 chimney caps and roof tiles blow away, children are blown over
10 zware storm 89-102 24,5-28,4 extensive damage to buildings, adults blown over
11 zeer zware storm 103-117 28,5-32,6 enormous damage to forests
12 orkaan >117 >32,6 devastation
